I reversed engineered the workings, and created a python upload script to push images.
Original workings are a mess. Per 4 bit of color, high-low switched in a byte. Black and red separated. Using a till p encoding over curl commands.
My implementation uses a python script called as:
python3 epaper-pusher.py ~/Downloads/Untitled.png
http://10.1.0.99/EPDI_
30 times something like
http://10.1.0.99/ppppppppppppppppppppppppppppppppppppppppppppppppppppppaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaabbbbbbbbbbbbbbbbppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppiodaLOAD_
http://10.1.0.99/NEXT_
30 times something like
http://10.1.0.99/pbcdefghijjjjjjffffffoooooooaaabbbbbbeeeedddppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppppiodaLOAD_
http://10.1.0.99/SHOW_
NOTES:
a = 0000
-
-
-
p = 1111 = 15
30 lines with 1000 bytes ( ending with iodaLOAD_ )
black pixels
first block 1
second block 0
red pixels
first block 0
second block 1
white pixels
first block 1
second block 1
PIXEL Example
RBRB
BWBW
First block
1010 - letter K
0101 - Letter F - second nibble = white
Second block
0101 - Letter F
1111 - Letter P - second nibble white
Code
from PIL import Image
import numpy
import requests
url="http://10.1.0.99/"
black_pixels = numpy.zeros((400,300))
red_pixels = numpy.zeros((400,300))
def classify_pixel_color(pixel):
"""
Classify a pixel as black, white, or red.
"""
r, g, b = pixel[:3] # Ignore alpha if present
# Define thresholds for classification
if r < 128 and g < 128 and b < 128:
return 'black'
elif r > 200 and g > 200 and b > 200:
return 'white'
elif r > 128 and g < 100 and b < 100:
return 'red'
else:
return None
def process_image(image_path):
"""
Process the image and classify its pixels into black, white, or red.
"""
image = Image.open(image_path)
image = image.convert("RGB") # Ensure the image is in RGB mode
width, height = image.size
pixel_data = image.load()
color_counts = {'black': 0, 'white': 0, 'red': 0}
for y in range (0, 299):
for x in range (0, 399):
black_pixels[x][y] = 0
red_pixels[x][y] = 0
for y in range(299):
for x in range(399):
color = classify_pixel_color(pixel_data[x, y])
if color:
color_counts[color] += 1
if color == 'black':
black_pixels[x][y] = 1;
if color == 'red':
red_pixels[x][y] = 1;
if color == 'white':
black_pixels[x][y] = 1;
red_pixels[x][y] = 1;
return color_counts, black_pixels, red_pixels
def number_to_letter(num):
"""
Translates a number from 0 to 15 into a corresponding letter (a-p).
Args:
num (int): The number to translate.
Returns:
str: The corresponding letter (a-p).
"""
if 0 <= num <= 15:
return chr(ord('a') + num)
else:
raise ValueError("Number must be between 0 and 15, inclusive.")
def print_array_in_chunks(array, chunk_size=1001):
current_chunk = ""
for item in array:
# Convert item to string and add to the current chunk
item_str = str(item)
if len(current_chunk) + len(item_str) + 1 > chunk_size:
# Print the current chunk and reset it
current_chunk += "iodaLOAD_"
try:
requests.get(url + current_chunk, verify=False)
if not response.content: # Equivalent to expecting an empty reply
pass
except requests.exceptions.RequestException as e:
# Catch any request-related errors
pass
current_chunk = item_str
else:
# Append the item to the current chunk
current_chunk += (item_str)
current_chunk += "iodaLOAD_"
# Print any remaining items in the chunk
if current_chunk:
try:
requests.get(url + current_chunk, verify=False)
if not response.content: # Equivalent to expecting an empty reply
pass
except requests.exceptions.RequestException as e:
# Catch any request-related errors
pass
def switch_in_pairs(arr):
# Loop through the array with a step of 2
for i in range(0, len(arr) - 1, 2):
# Swap values at index i and i+1
arr[i], arr[i + 1] = arr[i + 1], arr[i]
return arr
if __name__ == "__main__":
import sys
if len(sys.argv) < 2:
print("Usage: python3 script.py <image_path>")
sys.exit(1)
image_path = sys.argv[1]
try:
color_counts, black_pixels, red_pixels = process_image(image_path)
try:
requests.get(url + "EPDI_" , verify=False)
if not response.content: # Equivalent to expecting an empty reply
pass
except requests.exceptions.RequestException as e:
# Catch any request-related errors
pass
lines=[]
for y in range(300):
for x in range(0,399,4):
first = red_pixels[x][y]
second = red_pixels[x+1][y]
thirth = red_pixels[x+2][y]
fourth = red_pixels[x+3][y]
nibble = 0
if (first == 1):
nibble = nibble + 8
if (second == 1):
nibble = nibble + 4
if (thirth == 1):
nibble = nibble + 2
if (fourth == 1):
nibble = nibble + 1
lines.append(number_to_letter(nibble))
switched_array = switch_in_pairs(lines)
print_array_in_chunks(switched_array)
try:
requests.get(url + "NEXT_" , verify=False)
if not response.content: # Equivalent to expecting an empty reply
pass
except requests.exceptions.RequestException as e:
# Catch any request-related errors
pass
lines=[]
for y in range(300):
for x in range(0,399,4):
first = black_pixels[x][y]
second = black_pixels[x+1][y]
thirth = black_pixels[x+2][y]
fourth = black_pixels[x+3][y]
nibble = 0
if (first == 1):
nibble = nibble + 8
if (second == 1):
nibble = nibble + 4
if (thirth == 1):
nibble = nibble + 2
if (fourth == 1):
nibble = nibble + 1
lines.append(number_to_letter(nibble))
switched_array = switch_in_pairs(lines)
print_array_in_chunks(switched_array)
try:
requests.get(url + "SHOW_" , verify=False)
if not response.content: # Equivalent to expecting an empty reply
pass
except requests.exceptions.RequestException as e:
# Catch any request-related errors
pass
except Exception as e:
pass
Example is using my ledserver, see other post, but i intent to made a easy to configure node red panel where the to be controlled devices are preconfigured.
Cartridge not recognised? Just replace chip! With a original one
UPDATE: Maybe there is a counter in there, had a cartridge which wouldn’t work anymore ?!?
Cartridge saying .. i’m empty, but still visible ink?
Just tape up above part!
Note: there are many solutions found on the web, like opening the lid and pressing two buttons to get into a reset menu. Or Cold start your printer without cartrides 5 times to reset stored ink levels.
Below one of the two setups we made to control our TV. The kind of TV which was big, ungly and without remote.
This version used 3 strings. One for moving a little wooden piece to the left, one for moving to the right and one for pressing a bunch of nails agains a touch/capacitive button. (We only used channel 1 till 4 i believe)
The other version used a string per channel. A piece of metal, with at the end of it a little alumium-foil ball
Somewhere this year i got a subscription on HackTic a dutch hacker magazine.
Honestly most of the things i didn’t understand ( i was not into Unix at that time.)
I still got most of the magazines, except for some i lend to others and never got back.
In number 8 (1990) there was a schematic for copying magnetic strip cards. It took a while to build this, but i got it working in the end. I managed to get a working bank card copied onto my Film rental store card. And we managed to copy magnetic cards which would hold information about how many copies you could make at the school xerosmachines. So we copied a full card and when it was empty rewrote information on it to fill it again.
At the MTS in Hengelo we also had a hidden switch for the payphone to get our money back.
