Top IMDB followup using python (openpyxl)

Using some python and a scraped list I can now mark which movies we’ve seen, or have to see.
(Own the movie or have it seen streamed in the cinema)

I just have to place a X after the title in the first column.
Run the python script, and presto

First column, the list we started with.
Second column, mark the movie.
3rd until the end .. years 2000-2023

Blue – seen
Light Blue – seen but was not in original list (so a new movie)
Green – have this movie, but still have to watch it
Light Green – Have this movie but it’s not in the original list
Orange – New in that year (could be an oldie reemerging in the top 250)

Now the python script, maybe it useful for you.

# 20230813 18:49 IMDB overview
# pip install openpyxl

import openpyxl
from openpyxl.styles import PatternFill
from openpyxl.styles.colors import Color

wb = openpyxl.load_workbook("clearsheet.xlsx")
sheet = wb['Sheet1']

colors = ['00660066', '00FFFFCC',
          '007b8cf2', '005ace97', '00ffac58','00dddddd','009bd8ff','007aeeb7']
fillers = []

for color in colors:
    temp = PatternFill(patternType='solid',
                       fgColor=color)
    fillers.append(temp)

# Mark found previous years
for colt in range(4, 27):
    for colr in range(3, colt):
        for rowr in range(2, 252):
            for rowrr in range(2, 252):
                if sheet.cell(row=rowrr, column=colr).value == sheet.cell(row=rowr, column=colt).value :
                    sheet.cell(row=rowr, column=colt).fill = fillers[4]

# Mark Our Old list matched with all years
for titlerow in range(2, 252):
    for colr in range(3, 26):
        for rowr in range(2, 252):
            if sheet.cell(row=titlerow, column=1).value == sheet.cell(row=rowr, column=colr).value :
                sheet.cell(row=titlerow, column=1).fill = fillers[5]

# Mark Have / Seen
for title in range(2, 252):
    for j in range(3, 27):
        for i in range(2, 252):
            if sheet.cell(row=i, column=j).value == sheet.cell(row=title, column=1).value :
                if sheet.cell(row=title, column=2).value == "x":
                     sheet.cell(row=i, column=j).fill = fillers[2]
                else:
                     sheet.cell(row=i, column=j).fill = fillers[3]

# Mark non old list but seen
for title in range(252, 400):
    for j in range(3, 27):
        for i in range(2, 252):
            if sheet.cell(row=i, column=j).value == sheet.cell(row=title, column=1).value :
                if sheet.cell(row=title, column=2).value == "x":
                     sheet.cell(row=i, column=j).fill = fillers[6]
                else:
                     sheet.cell(row=i, column=j).fill = fillers[7]
# Info cells
sheet['D255'] = "Downloaded seen org list"
sheet['D256'] = "Downloaded not seen org list"
sheet['D257'] = "Title matches found in 2000-2023"
sheet['D258'] = "Titles found in 2000-2023 not in org list have"
sheet['D259'] = "Titles found in 2000-2023 not in org list have seen"
sheet['D260'] = "Titles found in 2000-2023 previous years"
sheet.cell(row=255, column=4).fill = fillers[2]
sheet.cell(row=256, column=4).fill = fillers[3]
sheet.cell(row=257, column=4).fill = fillers[5]
sheet.cell(row=258, column=4).fill = fillers[7]
sheet.cell(row=259, column=4).fill = fillers[6]
sheet.cell(row=260, column=4).fill = fillers[4]
wb.save("imdbexport.xlsx")

Python Spotify Genre Cube v2

Spotify version

Next to do: Lasercut a wooden cube with better lettering.

Run the python part on a server

and

First export some API credentials

export SPOTIPY_CLIENT_ID=xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
export SPOTIPY_CLIENT_SECRET=xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
export SPOTIPY_REDIRECT_URI="http://localhost:8080/callback"

Code below:

from flask import Flask, request, redirect
from requests_oauthlib import OAuth2Session
from requests.auth import HTTPBasicAuth
import requests
import json
import spotipy
from spotipy.oauth2 import SpotifyOAuth
from pprint import pprint
from time import sleep
import spotipy.util as util
import sys
import paho.mqtt.client as mqttClient
import time
import os
import subprocess

Connected = False


broker_address = "MQTTSERVER"
port = 1883


def on_connect(client, userdata, flags, rc):
    if rc == 0:
        print("Connected to broker")
        global Connected
        Connected =True
    else:
        print("Connection failed")

def on_message(client, userdata, message):
    print (message.payload)
    myurl = 'spotify:playlist:' + str(message.payload.decode())

    results = sp.start_playback(context_uri=myurl, offset={"position": 1})

client = mqttClient.Client("PythonSpotifyGenreCube")
client.on_connect = on_connect
client.on_message = on_message

client.connect(broker_address, port=port,keepalive=60 )
client.loop_start()
time.sleep(4) # Wait for connection setup to complete
client.subscribe('spotify/playlist')
#client.loop_stop()    #Stop loop

#while Connected != True:
#    client.loop()
#    time.sleep(0.1)
#    print("test")
#    client.subscribe('spotify/playlist')



app = Flask(__name__)

AUTH_URL = 'https://accounts.spotify.com/authorize'
TOKEN_URL = 'https://accounts.spotify.com/api/token'
REDIRECT_URI = 'http://localhost:8080/callback'
CLIENT_ID = "xxxxxxxxxxxxxxxxxx"
CLIENT_SECRET = "xxxxxxxxxxxxxxxxxxxxx"
SCOPE = [
    "user-read-email",
    "playlist-read-collaborative"
]

@app.route("/login")
def login():
    spotify = OAuth2Session(CLIENT_ID, scope=SCOPE, redirect_uri=REDIRECT_URI)
    authorization_url, state = spotify.authorization_url(AUTH_URL)
    return redirect(authorization_url)

@app.route("/callback", methods=['GET'])
def callback():
    code = request.args.get('code')
    res = requests.post(TOKEN_URL,
        auth=HTTPBasicAuth(CLIENT_ID, CLIENT_SECRET),
        data={
            'grant_type': 'authorization_code',
            'code': code,
            'redirect_uri': REDIRECT_URI
        })
    return json.dumps(res.json())


username = "fashice"
scope = "user-read-playback-state,user-modify-playback-state,playlist-read-private"
util.prompt_for_user_token(username,scope,client_id='xxxxxxxxxxxxxxxxxxxxx',client_secret='xxxxxxxxxxxxxxxxxxxxxxxxxxxx',redirect_uri='http://localhost:8080/callback')

sp = spotipy.Spotify(client_credentials_manager=SpotifyOAuth(scope=scope))

# Shows playing devices
res = sp.devices()
pprint(res)


# Change track
#sp.start_playback(uris=['spotify:track:6gdLoMygxxxxxxxxxxxxxxx'])
#results = sp.start_playback(context_uri=myurl, offset={"position": 1})


## Change volume
#sp.volume(100)
#sleep(2)
#sp.volume(50)
#sleep(2)
#sp.volume(100)
#


playlists = sp.user_playlists(username)

#for playlist in playlists['items']:
#    print(playlist['name'])


playlists = sp.current_user_playlists()
#print (playlists)
for playlist in playlists['items']:
    print(playlist['id'] + ' ' +  playlist['name'])



#if __name__ == '__main__':
#   app.run(port=8080,debug=True)


while Connected != True:
    time.sleep(0.1)
    client.subscribe('spotify/playlist')

try:
    while True:
        time.sleep(1)


except KeyboardInterrupt:
    print ("exiting")
    client.disconnect()
    client.loop_stop()

Bios hacking

Followup on :

I wrote a little python script which checks the checksum of a Bios.

In a previous post i used hexedit to play around changing a Bios dump.

Below posted python script calculates the checkum using the following:

Add all bytes in the file and do a modulo 256 on this number. The output should be 0.

My previous edit gave me a output of C2, so I changed an unused byte FF into (FF-C2) 3D.
No more checksum errors when booting!

Next to do, get a Bios like Glabios or PcXtBios to start my own code from a secondary Eeprom.

import sys

# Bios sum modulo should be 0
# edit  last or unused byte to fix
# python bios-checksum-test.py MYROM.edit.checksum
# 0

f = open(sys.argv[1],'rb')
m = f.read()
print  '%x' % ( ( sum(ord(c) for c in m) & 0xFFFFFFFF ) % 256 )

Python3

import sys

# Bios sum modulo should be 0
# edit  last or unused byte to fix
# python bios-checksum-test.py MYROM.edit.checksum
# 0

f = open(sys.argv[1],'rb')
m = f.read()
checksum =  ( ( sum((c) for c in m) & 0xFFFFFFFF ) % 256 )
print(checksum, 'in hex =', hex(checksum))

Spotify control using python

For usage in this project:

Goto https://developers.spotify.com and add a APP

Write down the Client_id Client_secret and Redirect URL (callback)

Create a bash and python script

#!/bin/bash
export SPOTIPY_CLIENT_ID=2f660e11e70743febdxxxxxxxxxxxxx
export SPOTIPY_CLIENT_SECRET=b0741452a4fe43xxxxxxxxxxxxx
export SPOTIPY_REDIRECT_URI="http://localhost:8080/callback"

python3 spot.py $1

spot.py

import spotipy
from spotipy.oauth2 import SpotifyOAuth
from pprint import pprint
from time import sleep
import spotipy.util as util
import sys

username = "username"
scope = "user-read-playback-state,user-modify-playback-state,playlist-read-private"
util.prompt_for_user_token(username,scope,client_id=SPOTIPY_CLIENT_ID,client_secret=SPOTIPY_CLIENT_SECRET,redirect_uri=SPOTIPY_REDIRECT_URI)

sp = spotipy.Spotify(client_credentials_manager=SpotifyOAuth(scope=scope))

# Shows playing devices
res = sp.devices()
pprint(res)

myurl = 'spotify:playlist:' + sys.argv[1]

# Change track
results = sp.start_playback(context_uri=myurl, offset={"position": 1})

## Change volume example
#sp.volume(100)
#sleep(2)
#sp.volume(50)
#sleep(2)

playlists = sp.user_playlists(username)

playlists = sp.current_user_playlists()
for playlist in playlists['items']:
    print(playlist['id'] + ' ' +  playlist['name'])

Run bash script as follows.

playlistplayspotify.sh 0bJvpsn0TDxxxxxxxxxxxx
(0bJvpsn0TDxxxxxxxxxxxx – is playlist ID, as example below)

OUTPUT:

python3 spot.py 0bJvpsn0TDxxxxxxxxxxxx
{'devices': [{'id': 'e86eada2a91e29a396acxxxxxxxxxxxxxxxxxxxx',
              'is_active': True,
              'is_private_session': False,
              'is_restricted': False,
              'name': 'laptop',
              'type': 'Computer',
              'volume_percent': 100},
             {'id': '8571468b6c41973ccb0axxxxxxxxxxxxxxxxxxxx',
              'is_active': False,
              'is_private_session': False,
              'is_restricted': False,
              'name': 'DESKTOP-xxxxxxx',
              'type': 'Computer',
              'volume_percent': 76},
             {'id': '6c592503aa5a22b2fbdxxxxxxxxxxxxxxxxxxxxxx',
              'is_active': False,
              'is_private_session': False,
              'is_restricted': False,
              'name': 'TX-NR1030',
              'type': 'AVR',
              'volume_percent': 41}]}
0bJvpsn0TDxxxxxxxxxxxx Best Classical Music Of All Time
5aL9jeGMCAxxxxxxxxxxxx Programming music
37i9dQZEVCxxxxxxxxxxxx Discover Weekly
6pEJuA1UYJxxxxxxxxxxxx Highland/Small/Border Pipe Music
5p8Tabf5Zwxxxxxxxxxxxx Folk Instrumentals ( Celtic, Irish, Nordic, ... )
1oy8Ek4ddBxxxxxxxxxxxx Lounge
37i9dQZF1Dxxxxxxxxxxxx Irish Folk
etc etc

Converting png images to composite pixels (6502)

Using searle’s design, i can draw pixels using composite video out.

Converting b/w png to hex include files, for usage in vasm I did the following.

#Python script to convert black levels to pixels
from PIL import Image
i = Image.open("fash.png")

pixels = i.load() # this is not a list, nor is it list()'able
width, height = i.size

all_pixels = []
for x in range(width):
    for y in range(height):
        cpixel = pixels[x, y]
        if cpixel[1] == 255:
            s = '\t.db 0x05,' + hex(int(x)) + ',' + hex(int(y))
            print (s)

Running and output example

python3 image.py > out

head out
	.db 0x05,0x1,0x16
	.db 0x05,0x1,0x18
	.db 0x05,0x1,0x19
	.db 0x05,0x2,0x7
	.db 0x05,0x2,0x8
	.db 0x05,0x2,0xc
	.db 0x05,0x2,0xd
	.db 0x05,0x2,0x17
	.db 0x05,0x3,0x5

Control codes and vasm include

01 (01) - Cursor home (Standard ASCII)
04 (04) - Cursor solid
05 (05) - Set graphics pixel (next two bytes = x,y)
0C (12) - Clear screen (Standard ASCII)
0D (13) - Carriage return (Standard ASCII)
0E (14) - Set column 0 to 79 (2nd byte is the column number) or 0 to 39 for a 40 char line
0F (16) - Set row 0 to 24 (2nd byte is the row number)
1B (27) - ESC - reserved for ANSI sequences

vasm include part:

message:
	.db 0x01,0x0c   ; home and clear
	.db 0x1b,0x2d   ; disable ansi translation
	include "out"   ; include hex "png"
	.db 0x00        ; end with 0 (part of message print routine)



I asked ChatGPT to write code for a Crack the Code game.

The Game

elcome to Crack the Code!
The code has 4 digits. Each digit is between 0 and 9.
You have 10 tries to guess the code.
After each guess, you will be told how many digits you got correct and how many were misplaced.
Good luck!
Enter your guess: 1234
Guess 1: 1234 - 0 correct, 0 misplaced
Enter your guess: 5678
Guess 2: 5678 - 2 correct, 1 misplaced
Enter your guess: 5689
Guess 3: 5689 - 1 correct, 2 misplaced
Enter your guess: 9688
Guess 4: 9688 - 1 correct, 2 misplaced
....
Sorry, you did not crack the code. The code was 5568.

Generated python code

import random

def generate_code():
    code = ""
    for i in range(4):
        code += str(random.randint(0, 9))
    return code

def check_guess(code, guess):
    correct_digits = 0
    misplaced_digits = 0
    for i in range(4):
        if guess[i] == code[i]:
            correct_digits += 1
        elif guess[i] in code:
            misplaced_digits += 1
    return (correct_digits, misplaced_digits)

def play_game():
    print("Welcome to Crack the Code!")
    print("The code has 4 digits. Each digit is between 0 and 9.")
    print("You have 10 tries to guess the code.")
    print("After each guess, you will be told how many digits you got correct and how many were misplaced.")
    print("Good luck!")
    code = generate_code()
    num_guesses = 0
    while num_guesses < 10:
        guess = input("Enter your guess: ")
        if len(guess) != 4 or not guess.isdigit():
            print("Invalid input. Please enter a 4-digit number.")
            continue
        num_guesses += 1
        correct, misplaced = check_guess(code, guess)
        print(f"Guess {num_guesses}: {guess} - {correct} correct, {misplaced} misplaced")
        if correct == 4:
            print("Congratulations! You cracked the code!")
            return
    print(f"Sorry, you did not crack the code. The code was {code}.")

play_game()

After this i let the AI made some changes, which kinda worked.
Scary nevertheless

Python Baudot code for Wemos Matrix Led

I wrote a python script to generate binary data to include in my Arduino sketch.
This Arduino displays codes send though MQTT.

https://en.wikipedia.org/wiki/Baudot_code

CODE:

python3 matrix.py apple gives me

byte apple_Char[8] = {
  0b00000000,
  0b01000100,
  0b01111000,
  0b00000000,
  0b00110000,
  0b00000000,
  0b00111000,
  0b00000000
};

Python Code
import sys

a = [
        [0,0,0,0,0,0,0,0 ],
        [0,0,0,0,0,0,0,0 ],
        [0,0,0,0,0,0,0,0 ],
        [0,0,0,0,0,0,0,0 ],
        [0,0,0,0,0,0,0,0 ],
        [0,0,0,0,0,0,0,0 ],
        [0,0,0,0,0,0,0,0 ],
        [0,0,0,0,0,0,0,0 ]
    ]

letters = [
        [0,1,1,0,0,0,0,0 ],
        [0,1,0,0,0,1,1,0 ],
        [0,0,1,0,1,1,0,0 ],
        [0,1,0,0,0,1,0,0 ],
        [0,1,0,0,0,0,0,0 ],
        [0,1,0,0,1,1,0,0 ],
        [0,0,1,0,0,1,1,0 ],
        [0,0,0,0,1,0,1,0 ],
        [0,0,1,0,1,0,0,0 ],
        [0,1,1,0,0,1,0,0 ],
        [0,1,1,0,1,1,0,0 ],
        [0,0,1,0,0,0,1,0 ],
        [0,0,0,0,1,1,1,0 ],
        [0,0,0,0,1,1,0,0 ],
        [0,0,0,0,0,1,1,0 ],
        [0,0,1,0,1,0,1,0 ],
        [0,1,1,0,1,0,1,0 ],
        [0,0,1,0,0,1,0,0 ],
        [0,1,0,0,1,0,0,0 ],
        [0,0,0,0,0,0,1,0 ],
        [0,1,1,0,1,0,0,0 ],
        [0,0,1,0,1,1,1,0 ],
        [0,1,1,0,0,0,1,0 ],
        [0,1,0,0,1,1,1,0 ],
        [0,1,0,0,1,0,1,0 ],
        [0,1,0,0,0,0,1,0 ]
        ]

number=0
word=str(sys.argv[1])

for col in range(len(word)) :
    character=word[col]

    number = ord(character) - 97
    nextcol = col + 1
    for row in range(len(a[col])) :
        a[row][nextcol] = letters[number][row]


print("byte " + word + "_Char[8] = {")
for i in range(len(a)) :
    print("  0b", end = '')
    for j in range(len(a[i])) :
        print(a[i][j], end="")
    if i < 7:
        print(",")
print()
print("};")

Arduino test code

#include <ESP8266WiFi.h>
#include <PubSubClient.h>
#include <WiFiClient.h>


#include "WEMOS_Matrix_LED.h"
MLED mled(5); //set intensity=5

const char* wifi_ssid = "MYSSID"; // Enter your WiFi name
const char* wifi_password =  "MYSSIDPASS"; // Enter WiFi password
const char* mqtt_server = "MYMQTTSERVER";
const int mqtt_port = 1883;
const char* mqttUser = "";
const char* mqttPassword = "";
#define MSG_BUFFER_SIZE  (50)
char msg[MSG_BUFFER_SIZE];
int value = 0;

WiFiClient espClient;

PubSubClient mqtt(espClient);

void setup_wifi() {
  delay(10);
  WiFi.mode(WIFI_STA);
  WiFi.begin(wifi_ssid, wifi_password);
  while (WiFi.status() != WL_CONNECTED) {
    delay(500);
  }
}

byte clear_Char[8] = {
  0b00000000,
  0b00000000,
  0b00000000,
  0b00000000,
  0b00000000,
  0b00000000,
  0b00000000,
  0b00000000
};

byte baudot_Char[8] = {
  0b11111111,
  0b01101010,
  0b00011100,
  0b11111111,
  0b00110100,
  0b00010000,
  0b00000100,
  0b11111111
};



#define TIME 500

void setup() {
    Serial.begin(115200);
      setup_wifi();
        mqtt.setServer(mqtt_server, mqtt_port);

WiFiClient espClient;
PubSubClient mqtt(espClient);

  mqtt.setClient(espClient);
  mqtt.setServer(mqtt_server, mqtt_port);
      delay(500);

  mqtt.subscribe("escape/matrixledin");
        delay(500);

  mqtt.setCallback(callback);

  }

void callback(char* topic, byte* payload, unsigned int length) {
        Serial.println("callback");
    String topicStr = topic;
      byte value = atoi((char*)payload);
        snprintf (msg, MSG_BUFFER_SIZE, "%1d", value);

              mqtt.publish("escape/matrixledout", msg);
       if (value == 1){

drawChar(baudot_Char);

 }else if (value == 0){
  drawChar(cleat_Char);
  }else if (value == 2){
  drawChar(test_Char);
  }else if (value == 3){
  drawChar(no_Char);
 }
 }

void reconnect() {

  while (!mqtt.connected()) {
    String clientId = "matrixClient-";
    clientId += String(random(0xffff), HEX);
    if (mqtt.connect(clientId.c_str())) {
      mqtt.publish("escape/outTopic", "hello from 8x8led module");
                Serial.println("resubscribe");

      mqtt.subscribe("escape/matrixledin");
        mqtt.setCallback(callback);

    } else {
      // Wait 5 seconds before retrying
      delay(5000);
    }
  }
}

void loop() {

 if (!mqtt.connected()) {
          Serial.println("reconnect called");
    reconnect();
  }
    mqtt.loop();

}

void drawChar(byte character[8]) {
  for(int y=7;y>=0;y--) {
  for (int x=0; x <= 7; x++) {
    if (character[(7-y)] & (B10000000 >> x)) {
     mled.dot(x,y); // draw dot
    } else {
     mled.dot(x,y,0);//clear dot
    }
  }
  mled.display();
  }
}

Playing with lasercutter steppermotors

Busy day: I’ve airbrushed some 3D pieces a few days ago, but i need 50 or so more.
Meanwhile is was reinstalling octoprint, and making a new version of my Bluetooth page flipper. (Android Music Sheet Pedal Thingy. Which i also didn’t post apparently)
But the main project was this:

I was curious how fast the stepper motors are on my laser cutter. And for what can we utilize this!

So I took a Raspberry Zero and some rotary encoders, lets make an etch-a-sketch like thingy.


Some rotary encoder modules I had.

Next to do: 3D print a pen holder, and alter the code to enable the laser when moving!

CODE

Below code uses a simple rotary class, and generates control GCodes for the steppers/Sculpfun

import time
import serial
import RPi.GPIO as GPIO
from encoder import Encoder

def valueChanged(value, direction):
    print("* New value: {}, Direction: {}".format(value, direction))

GPIO.setmode(GPIO.BCM)

e1 = Encoder(20, 21, valueChanged)
e2 = Encoder(16, 12, valueChanged)

x = 0
y = 0
arduino = serial.Serial('/dev/ttyUSB0', 115200, timeout=.1)

newx = 0
mystringx = ""
newy = 0
mystringy = ""

arduino.write(str.encode("G00 G17 G40 G21 G54\r\n"))
arduino.write(str.encode('G90\r\n'))
arduino.write(str.encode('M4\r\n'))
arduino.write(str.encode('M8\r\n'))
arduino.write(str.encode('G0 X41.5Y36.05\r\n'))
arduino.write(str.encode('M3\r\n'))
#arduino.write(str.encode('G91\r\n'))
arduino.write(str.encode('G1 X2.5F6000S0\r\n'))
arduino.write(str.encode('G1 X0\r\n'))
arduino.write(str.encode('G1 Y0\r\n'))

try:
    while True:
        data = arduino.readline()[:-2] #the last bit gets rid of the new-line chars
        if data:
                print (data)
        arduino.write(str.encode("G1 F10000\r\n"))
        newx=e1.getValue() *5 + 100
        newy=e2.getValue() *5 + 100
        mystringx=f"G1 X{newx}\r\n"
        mystringy=f"G1 Y{newy}\r\n"
#        print(mystringx)
        arduino.write(str.encode(mystringx))
        arduino.write(str.encode(mystringy))

except Exception:
    pass

GPIO.cleanup()

Movie to txt in dutch

In the past i’ve converted some VHS movies speech to text, using all kinds of tools.
Lets use some opensource tools!

pip install moviepy
pip install SpeechRecognition

Create a python script with the following:
(Called mine wav2txt.py)

import math, contextlib
import speech_recognition as sr
from moviepy.editor import AudioFileClip
movie_audio_file_name = "movieadiofile.wav"
with contextlib.closing(wave.open(movie_audio_file_name,'r')) as f:
    frames = f.getnframes()
    rate = f.getframerate()
    duration = frames / float(rate)
total_duration = math.ceil(duration / 60)
r = sr.Recognizer()
for i in range(0, total_duration):
    with sr.AudioFile(movie_audio_file_name) as source:
        audio = r.record(source, offset=i*60, duration=60)
    f = open("transcription.txt", "a")
    f.write(r.recognize_google(audio, language="nl-NL"))
    f.write(" ")
f.close()

Now convert a movie to wav using below.

ffmpeg -i /fileserver/path/koolhoven.mkv movieaudiofile.wav

run python3 wav2txt.py

output
(Note .. these are not timestamped for subtitles)
I only needed the things being said in the home movie recordings as text.

Ik zit hier in de film The James Dean aan de
wereld voorstelde en daarmee de tienerfilm ingeleverd introduceren zelden werden onrustige 10 asiel zo mooi blootgelegd als ik deze film van Nicolas bij en dat wordt dan meteen toevallig even de mooiste
titels ooit wel eens autocross vanavond kijken we naar de kom ik nog even veel zomer dat je voor het eerste meisje Zoem de eerste baantje

etc..

Raspberry Zero with display

I’ve installed a headless Raspbian on a Pi Zero with a 2×16 Chars lcd display. As part of the Escape Room over the internet

Using the raspberry imager:
I’ve set the username/password and ssh access in this tool.
For wifi access i’ve placed below file on the SDcard in /boot
(You can do this in the tool, but i want to make this dynamic when connected at a remote site.)
file: wpa_supplicant.conf

country=NL
update_config=1
ctrl_interface=/var/run/wpa_supplicant

network={
 scan_ssid=1
 ssid="MYSSID"
 psk="MYSSIDPASS"
}

ssh into the RPi

sudo raspi-config
Interface options and enable I2C

sudo apt-get install python3-smbus

wget https://gist.githubusercontent.com/DenisFromHR/cc863375a6e19dce359d/raw/36b82e787450d127f5019a40e0a55b08bd43435a/RPi_I2C_driver.py
and
wget https://gist.githubusercontent.com/DenisFromHR/cc863375a6e19dce359d/raw/36b82e787450d127f5019a40e0a55b08bd43435a/examples.py

For python3 edit the example and put at the top

# requires RPi_I2C_driver.py
import RPi_I2C_driver
from time import *
unichr = chr

Run with
python3 examples.py
lcd display with i2c backpack
I2C backpack

Below is a mockup session.

Next todo:

  • Add more hardware (like buttons) to the RPI
  • Configure an Accesspoint on this Rpi for other devices to connect to
  • Install a local Mqtt broker, which connects secure to my internet facing broker
Setup example
